Laser diode, 450 nm, 2 W, in a 5.6 mm can: the metal cap with its window on the round base, the pins pointing backwards; a beam is drawn leaving the window.1 / 3
Laser diode, 450 nm, 2 W, in a 5.6 mm can: the metal cap with its window on the round base, the pins pointing backwards; a beam is drawn leaving the window.Laser diode, 450 nm, 2 W, in a 5.6 mm can: close-up of the metal cap and its window.Laser diode, 450 nm, 2 W, in a 5.6 mm can: the underside of the base with its pins.

2W 450nm Laser Diode

2 W 450 nm Osram Laser Diode

€46.22excl. VAT

Part no.: PD-01219

Made to order · lead time approx. 7 days

Optical output power
2000 mW
Wavelength
450 nm
Package
5.6 mm
Operating current
1200 mA

Specifications

Optical output power
2000 mW
Wavelength
450 nm
Wavelength tolerance
±10 nm
Transverse mode
Multi mode
Package
5.6 mm
Operating voltage
4.6 V
Beam divergence
10 × 48 °
Polarization
100:1
Operating current
1200 mA
Threshold current
100 mA

Pin Assignment

Ø 5.6 mm123
Rear view
1Anode (LD)
2Case
3Cathode (LD)
